Rod connections for 4 Areas

BP04230
€157.44 €224.91 -30%
Tax included
Si no sabes qué elegir
¿Qué termostato necesito? Flecha

Command bar, device that facilitates the installation of up to 4 independent zones, by connecting thermostats or chronothermostats with wires.

With this bar we will be able to regulate the temperature of up to 4 different areas of the home.

Estimated delivery date: 16 March 2026


CHARACTERISTICS Rod connections for 4 Areas:

  • Power 230V AC - 50Hz.
  • Potential free contact: 10A / 250V AC
  • Output for active pump command with at least one open-zone valve.
  • Output ordered by time switch.
  • Exit Summer / Winter ordered remotely
  • WINTER operation indication LED.
  • LED indication of operation SUMMER
  • LED command indication pump ON / OFF.
  • Degree protection IP30
