Gas thermostatic heater HELIOS

CHARACTERISTICS OF THE HELIOS Gas Thermostatic Heater:

• Compact dimensions.
• Brass water body.
• Automatic gas power modulation.
• Automatic and progressive ignition.
• Low ignition flow and pressure.
• Temperature regulation.
• Ionization safety.
• Ease of maintenance.
• Battery powered.
• Limestone protection.
• Low battery indicator LED.
• Overtemperature safety.
• Safety at overpressure of water.
• Evacuation safety (interior model B11BS).
• Includes installation accessories.

TECHNICAL CHARACTERISTICS:

• Type: Open Chamber
• Power: 1.5v battery
• Flame Control: Ionization
• Gas modulation: Electronic variable
• Hot water production (∆t = 25 ° C): 11 L / Min.
• Nominal thermal consumption: 21.5 Kw
• Useful thermal power: 18.8 Kw
• Dimensions: 620 x 325 x 202 mm.
• Weight: 10.5 Kg.
• Gas: Natural gas - butane / propane
• Flow range: 2.8 - 11
• Minimum ignition pressure: 0.1 bar
• Maximum pressure: 10 bar
• Hydraulic fitting connection: 1/2 "
• Nominal pressure of natural gas supply: 20 mbar
• LPG supply pressure (G30 / G31): 30/37 mbar
• Gas fitting connection: 1/2 "
• Gas evacuation - diameter: 110 mm.
